Laser Welding Solutions

Join, seal, and fabricate with submillimeter accuracy using advanced Laser Beam Welding (LBW). Deliver narrow, deep weld seams with minimal thermal distortion across dissimilar metals and thin-walled assemblies.

ABB Robot
Automation

0.2 – 2.5 mm
Thickness Range

6 Metals
Material Types

Job Work
Service Type

Machine & Process Details

Machine	ABB Robot
Process	Laser Welding

Compatible Materials

Mild Steel (MS)

Stainless Steel (SS304/SS316)

Aluminium

Copper

Brass

Nickel Alloys

Capability / Thickness Range

Range / Details

0.2 mm to 2.5 mm welding

Key Process Points

Robotic laser welding using ABB 6-axis arm for consistent, repeatable weld quality
Suitable for thin sheet metals starting from 0.2 mm without burn-through
Maximum thickness capacity of 2.5 mm in a single pass
Works on both ferrous (MS, SS) and non-ferrous (Aluminium, Copper, Brass, Nickel Alloys) materials
Automated path programming ensures uniform weld bead geometry across production batches
Minimal heat-affected zone due to focused laser beam

Typical Applications

Automotive sheet metal components and body assemblies
Stainless steel enclosures and housings
Copper and brass assemblies for electrical components
Nickel alloy parts for high-temperature applications
Thin-wall structures requiring low distortion

Notes : Material type and joint fit-up quality directly impact weld quality. Fixtures and jigging provided/supported for repeat production jobs.
